FQ4401 Stainless Steel Pressure Transducer for Selected Hazardous-Environment Projects
Stainless steel pressure transducer for gas compression, wellhead equipment, industrial OEM, and selected hazardous-environment projects requiring document review.
The FQ4401 is a media-isolated stainless steel pressure transducer for demanding gas, wellhead, pipeline, and industrial OEM applications. Its sensing structure is oil-free, weld-free, and O-ring-free. Manufacturer documentation states an Ex ia IIC T6 marking, but the certificate package, entity parameters, safety barrier, project jurisdiction, and installation approval must be verified before hazardous-location use. Wetted-material compatibility must also be confirmed for each medium and operating condition.
- ▶Gas compression and storage systems
- ▶Wellhead and pipeline pressure monitoring
- ▶Oil & gas platform equipment
- ▶Demanding industrial measurement requirements
- ▶Selected hazardous-environment projects requiring certification and installation review
For general industrial OEM, water systems, or refrigeration applications, review FQ3100 General-Purpose Pressure Transducer.
Manufacturer Documentation Notice
Manufacturer documentation states an Ex ia IIC T6 marking. Zylo does not present that statement as ATEX, IECEx, CSA, UL, or FM approval. The applicable certificate package, entity parameters, safety barrier, project jurisdiction, and installation approval must be verified before hazardous-location use. Contact us to coordinate a project-specific documentation review.
Performance
- Accuracy
- ±0.25% BFSL max
- Stability
- ±0.25% FS/year, typical
- Pressure Cycles
- >100 million full-scale cycles
Range
- Min Range
- 0–2 bar / 0–25 psi
- Max Range
- 0–700 bar / 0–10,000 psi
- Overrange
- 2× rated pressure
Environmental
- Operating Temp
- -40 to 85°C
- Protection
- IP66
- EMC
- Protected
Mechanical
- Shock
- 100 g, 11 msec, ½ sine
- Vibration
- 10 g peak, 20–2,000 Hz
- Technology
- Monolithic stainless steel media-isolated sensing element
- ✓Available for selected hazardous-environment and gas-service projects after documentation review
- ✓Accuracy: ±0.25% BFSL max
- ✓Rugged all-stainless steel construction
- ✓Oil-free, weld-free, O-ring-free media-isolated design
- ✓Wide operating temperature: −40 to 85°C
- ✓Standard ranges from 0–25 to 0–10,000 psi; compound or vacuum configurations require factory review
- ✓316L option available; media compatibility requires project-specific review
- ✓EMI/RFI shielded
The configuration code is a preliminary reference. Final range and unit compatibility, wiring, documentation, and availability are confirmed in the quotation.
Full Specifications
4–20 mA (2-wire)
1–5 VDC / 1–6 VDC
0–50 mV
0.5–4.5 V Ratiometric
Oil & Gas
Pressure measurement for upstream, midstream, and downstream operations. Selected models can enter project-specific hazardous-area review.
Hydrogen & Fuel Cell
Selected 316L configurations can be evaluated for fuel-cell, hydrogen-storage, and distribution projects. Final suitability depends on the complete operating conditions.
Industrial OEM
Pressure sensors for integration into industrial machinery, hydraulic systems, and automated equipment. Compact form factors and multiple output options.
Ready to Order?
Share your pressure range, media, output, and process connection. We will help identify a suitable configuration for review and provide a quotation.
